ACS Stranded Conductor

ACS-Aluminum Clad Steel Stranded cable

ACS-Aluminum Clad Steel Wire

Aluminum Clad Steel (ACS) is a high-strength steel wire with a thick aluminum coating. The ACS wire consists of a central steel core and a layer of high-conductivity aluminum extruded onto it.

Share

Construction

Aluminum clad steel wire is a kind of bimetallic wire that aluminum covers the steel core continuously and evenly.

Application

ACS wire is commonly used in overhead power transmission and distribution lines. It is also used in grounding systems and other applications where corrosion resistance is important.

Feature

The advantages of ACS wire is that it has a lower thermal expansion coefficient than aluminum wire, which means it is less likely to sag or break due to temperature changes.

Additionally, the steel core helps to reduce the overall weight of the wire, making it easier to handle and install.

Standard

ASTM, BS, DIN, JIS,etc

ACS Stranded Conductor

    Nominal diameter

Cross-section

mm2

Min. tensile
strength MPa

Calculated
breaking load
kN

Min. coating
thickness mm

Max. DC resistance
at 20C Q/km

Approx. weight

kg/km

mm

AWG

2.052

12

3.307

1340

4.5

0.103

25.64

21.80

2.304

11

4.169

1340

5.6

0.115

20.34

27.49

2.589

10

5.260

1340

7.1

0.130

16. 12

34.66

2.904

9

6.633

1340

8.9

0.145

12.78

43.65

3.264

8

8.367

1340

11.2

0.163

10. 14

55. 14

3.477

7

9.495

1310

12.4

0.174

8.93

62.57

3.665

7

10.55

1280

13.5

0.183

8.04

69.48

3.934

6

12. 16

1240

15.1

0.197

6.93

80. 13

4.115

6

13.30

1210

16.0

0.206

6.38

87.62

4.392

5

15. 15

1170

17.7

0.220

5.60

99.84

4.620

5

16.76

1140

19.1

0.231

5.06

110.50

4.775

4

17.91

1100

19.7

0.239

4.73

118.0

5.189

4

21. 15

1070

22.6

0.259

4.01

139.34

No./size of

strands

Cross-

section

No. of wires

    Diameter

Approx. weight

Rated strength

Max. DC
resistanc
e at 20C

Wire

Conductor

AWG

mm2



mm

mm

kg/km

kN

Q/km

3 No. 5

50.32

3

4.62

9.96

334.1

54.42

1.6990

3 No. 6

39.80

3

4.11

8.87

265.0

45.74

2.1420

3 No. 7

31.65

3

3.67

7.90

210.1

38.36

2.7010

3 No. 8

25. 10

3

3.26

7.03

166.7

32.06

3.4060

3 No. 9

19.90

3

2.91

6.26

132.2

25.43

4.2940

3 No. 10

15.78

3

2.59

5.58

104.8

20. 16

5.4150

7 No. 5

117.40

7

4.62

13.90

781.1

120.27

0.7426

7 No. 6

93. 10

7

4.11

12.40

619.5

101.14

0.9198

7 No. 7

73.87

7

3.67

11.00

491.1

84.81

1.1600

7 No. 8

58.56

7

3.26

9.78

389.6

70.88

1.4630

7 No. 9

46.44

7

2.91

8.71

308.9

56.20

1.8440

7 No. 10

36.83

7

2.59

7.76

245.1

44.58

2.3250

7 No. 11

29.21

7

2.30

6.91

194.4

35.35

2.9320

7 No. 12

23. 16

7

2.05

6.16

154.2

28.03

3.6970

19 No. 5

318.70

19

4.62

23. 10

2129.0

326.39

0.2698

19 No. 6

252.70

19

4.11

20.60

1688.0

 274.55

0.3402

19 No. 7

200.40

19

3.67

18.30

1339.0

 230.18

0.429

19 No. 8

158.90

19

3.26

16.30

1062.0

192.41

0.5409

19 No. 9

126.10

19

2.91

14.50

842.0

152.58

0.6821

19 No. 10

99.96

19

2.59

12.90

667.7

121.00

0.8601

37 No. 5

620.60

37

4.62

32.30

4170.0

635.43

0.1394

37 No. 6

492.20

37

4.11

28.80

3307.0

534.85

0.1757

37 No. 7

390.30

37

3.67

25.70

2623.0

448.09

0.2216

37 No. 8

309.50

37

3.26

22.90

2080.0

374.67

0.2794

37 No. 9

245.50

37

2.91

20.30

1649.0

279.11

0.3523

37 No. 10

194.70

37

2.59

17.90

1308.0

235.61

0.4443



If this page does not have the model you want, or if you need custom cable service, please contact us and we will be happy to assist you.
