ARG16R16 Power cable
Power cable 0,6/1 kV with Al conductors, rubber G16 insulated and PVC sheathed.
Construction
- Conductors: Al, class 2 according to EN 60228
- Insulation: G16 rubber
- Bedding: Extruded elastomere or plastomere
- LS0H compound
- Sheath: PVC compound R16 quality, gray
Tehnical characteristics
- CPR class: Cca – s3,d1,a3
- Test voltage: 4 Kv
- Rated voltage: 0,6/1 kV
- Bending radius (min): single-core – 15D
- Min. laying temperature: -15°C
- Max. conductor temperature: 90°C
- Max. short-circuit temperature: 250°C
| CROSS SECTION | MAXRESIS- TANCEAT 20°c | INSULATION THICKNESS | SHEATH THICKNESS | CURRENT CAPACITY IN AIR 30°C | CURRENT CAPACITY IN PIPE IN AIR 30°C | CURRENT CAPACITY BURRIED 20°C | CURRENT BURRIED PI | CAPACITY PE 20°C | OUTER DIAM (APPROX.) | CABLE WEIGHT (APPROX.) | |
| mm² | Ω/km | mm | mm | A | A | A | A | A | A | mm | kg/km |
| K=1 | K=1,5 | K=1 | K=1,5 | ||||||||
| 1×16 | 1,910 | 0,7 | 1,4 | 70 | 64 | 98 | 89 | 75 | 70 | 10,0 | 150 |
| 1×25 | 1,200 | 0,9 | 1,4 | 102 | 88 | 119 | 110 | 95 | 88 | 11,7 | 185 |
| 1×35 | 0,868 | 0,9 | 1,4 | 136 | 110 | 141 | 131 | 115 | 106 | 13,0 | 220 |
| 1×50 | 0,641 | 1,0 | 1,4 | 164 | 131 | 167 | 154 | 134 | 124 | 14,7 | 280 |
| 1×70 | 0,443 | 1,1 | 1,4 | 218 | 175 | 204 | 189 | 173 | 160 | 16,6 | 320 |
| 1×95 | 0,320 | 1,1 | 1,5 | 261 | 209 | 245 | 226 | 196 | 181 | 18,6 | 460 |
| 1×120 | 0,253 | 1,2 | 1,5 | 310 | 250 | 277 | 256 | 238 | 220 | 20,5 | 570 |
| 1×150 | 0,206 | 1,4 | 1,6 | 350 | 280 | 313 | 289 | 250 | 231 | 22,8 | 670 |
| 1×185 | 0,164 | 1,6 | 1,6 | 415 | 334 | 350 | 324 | 300 | 278 | 25,0 | 810 |
| 1×240 | 0,125 | 1,7 | 1,7 | 490 | 392 | 413 | 382 | 331 | 306 | 27,9 | 1025 |
| 1×300 | 0,100 | 1,8 | 1,8 | 567 | – | 454 | 420 | 400 | 370 | 30,7 | 1205 |
| 1×400 | 0,0778 | 2,0 | 1,9 | 665 | – | 5112 | 474 | 450 | 417 | 35,0 | 1660 |
| 1×500 | 0,0605 | 2,2 | 2,0 | 765 | – | 578 | 535 | 505 | 4648 | 38,6 | 1940 |
| 1×630 | 0,0469 | 2,4 | 2,2 | 880 | – | 646 | 598 | 580 | 537 | 43,1 | 2460 |
