PVC/PVC Flame Fire Cable
- Voltage: 0.6/1kv
- Core: 1,2,3,4,5,3+1,3+2,4+1, cores
- Conductor: Cu or Aluminum/Tinned Copper
- Sheath Color: Black or Colors
- Insulated: PVC
- Sheath: PVC, PE or LSZH
- Feature: Flame retardant PVC insulated PVC sheathed power cable (FR/PVC/PVC Cable)
- Standard: IEC60502,BS 7870,GB/T12706 or other standard can customized.
- Application: It applies to electrical power transmission and distribution lines with AC rated voltage U0/U up to and including 0.6/1 kV. For outdoor and indoor installation in damp and wet locations.
parameter
Working
- 1. The long time working temperature is at 90℃, suffer short circuit (within 5 seconds), the temperature of core can not higher than 250℃
- 2. The ambient temperature should not lower than -10℃
- 3. The laying temperature should not lower than 0℃
- 4. Single core’s bend radius with no armor should not exceed 20D,single core’s bend radius with armor should not exceed than 15D,three cores’ bend radius with armor should not exceed 12D
